Guangzhou Winson Information Technology Co., Ltd.
$451-49 Others
$3550-199 Others
$28≥200Others
| Tipo di pagamento: | L/C,T/T,D/P,D/A,Paypal,Others |
| Incoterm: | FOB,CFR,CIF,EXW,DDP |
| Trasporti: | Ocean,Land,Air,Express,Others |
| Porta: | guangzhou |
Modello: WNI-S214
marchio: Winson
Certificazione: ce
Stato Del Prodotto: Azione
Tipi Di: Scanner di codici a barre
Tipo Di Elemento Di Scansione: CCD, CMOS
Punto Di Colore: 32 bit
Tipo Di Interfaccia: USB
Luogo D'origine: Cina
Periodo Di Garanzia (anni): 1 anno
Assistenza Post-vendita: Restituzione e sostituzione
Private Mold: Yes
Products Status: Stock
Type: Barcode Scanner
Scan Element Type: Cmos
Colour Depth: 32 Bit
Interface Type: Usb, Rs232
Max Paper Size: N/A
Optical Resolution: 640X480 pixels
Scan Speed: 350 ±50 scans/second
Brand Name: Winson
Place Of Origin: Guangdong, China
Warranty(Year): 1-Year
After-sales Service: Call Center And On-Line Technical Support
Software Development Kit (SDK): NO
Color: Blue, Black
Product Type: QR Code Scanner
Interface: USB HID KEYBOARD/USB VCP
Photo Sensor: CMOS array sensor
Voltage Requirement: DC5V±10%
Dimensions: 90mm*67mm*168mm
Weight: 130g
Indicator: Beeper, LED
| Unità vendibili | : | unit |
| Tipo pacchetto | : | Imballaggio personalizzato (negoziato) 1pcs/box, 20/50pcs/cartone |
| Esempio immagine | : |
|
The file is encrypted. Please fill in the following information to continue accessing it
Software POS gratuito Leggi il codice a barre piccolo come 3,3 mulini.
Supporto scanner per scopi generici per inserire il prefisso o il suffisso prima o dopo scansionare i dati, attivare/ disattivare il buzzer, tipo di codice a barre di identità, aggiungere tasti tastiera (scheda, CR & lf, ecc.)
Campi di applicazione scanner per cavi : supermercato, vendita al dettaglio, magazzino, logistica, biblioteca, medica ecc.
|
Wireless Characteristics |
|
|
Communication mode |
Cache mode/Inventory mode |
|
Communication mode |
2.402 to 2.480GHz |
|
Transmission range |
30m(In empty area) |
|
Battery capacity |
2000mAh (Lithium battery) |
|
Charge Time from Empty to Full Charge |
5H |
|
Duration of use |
11H (wireless mode,real-time mode communication mode,60 scans/minute) |
|
Electrical Characteristics |
|||
|
Interface Supported |
USB HID KEYBOARD/USB VCP or RS-232 |
||
|
Input Voltage |
DC 5V |
||
|
Current |
150mA |
||
|
Performance Characteristics |
|||
|
Sensor |
640×480 CMOS |
||
|
Illumination |
White LED |
||
|
Focus |
Red LED |
||
|
Scanning Angle |
Pitch angle:+55° |
||
|
|
Skew angle:+360° |
||
|
|
Tilt angle:+55° |
||
|
Field of view |
36°(H),27°(V) |
||
|
Reading accuracy |
≥5mil |
||
|
Decode Capability |
1D:Code 128,Ean-13 ,Ean-8,UPC-E,UPC-A,ITF-25(Interleaved 2 0f 5),Code39,Code93,Codabar 2D:QR Code,Data Matrix,PDF417 |
||
|
Environmental Characteristics |
|||
|
Temperature |
operation:-20°C to 60°C |
||
|
|
storage:-40°C to 80°C |
||
|
Humidity |
operation:5%~95% (no condensation) |
||
|
Ambient light |
0~100,000LUX |
||
|
Decoding Depth of Field |
|||
|
Symbology |
Resolution |
Barcode number |
Barcode width |
|
Code128 |
13mil |
10 |
4.3x3.1cm |
|
Code39 |
5mil |
7 |
3.5x1.19cm |
|
EAN13 |
13mil |
13 |
4.5x2.69cm |
|
QR Code |
15mil |
30 |
1.9x1.85cm |
|
Data Marix |
10mil |
30 |
4.5x1.16cm |
|
PDF 417 |
6.67mil |
30 |
4.0x10.5cm |
